★ This is the automatic centrifuge dryer use sample diagram, this product doesn’t include chip conveyor and oil collection tank.
★ This is the automatic centrifuge dryer using sample diagram, the chip conveyor and bottom are options.
Performance
▪ Continues, non-stop
▪ Automatic chips outlet
▪ 1000rpm centrifuge, fast and dry
▪ 85%+ recycling
★ The chips dryer is suitable for 3~50mm length gundrill chips. The Shredder is suggested when the chips are longer.
Modle | D1 |
Throughput chips | 300 L/h |
Max. Speed | 1,150 rpm |
RCF | 400 *g |
Drum diameter | 540 mm |
Chips inlet Size | Ø640 mm |
Chips inlet height | 1165 mm |
Chips outlet height | 580 mm |
Machine weight | 600 kg |
Volume litre | 25 L |
★This is the automatic centrifuge dryer use sample diagram, this product doesn't include chip conveyor, oil collection tank, chips crusing machine and chips compactor. | |
Modle | DC1 |
Geared motor | 0.2kw 1/4HPx4p 220/380V (50/60Hz) |
Reduction ratio | 1/165 |
The chain | 400 *g |
Chip speed | 540 mm |
Safety devices | Overload protection |
Modle | DT1 |
Size | 1600 x 814 x 180 mm |
Volume litre | 160 L |
Modle | DB1 | DB2 |
Machine size | 725 x 683 x 870 mm | 650 x 600 x 250 mm |
Power and Voltage | 3Φ / 220v / 60Hz | |
Weight | 100 kg | |
Spindle motor | 2HP (1.5kw) | |
Spindle speed | 19 rpm | |
Shredding room size | 215 x 130 mm | 215 x 130 mm |
Cutter material | SKD11 | |
Chips inlet size | 500 x 500 x 220 mm | 500 x 500 x 180 mm |
Modle | DY1 |
Max. compression force | 100 tons |
Max. working pressure | 210 kg/cm² |
Chip cross-section Dia. | Ø90 |
Compression surface pressure | 1570 kg/cm² |
Oil tank volume | 120 L |
Motor of compression cylinder | 5.5 kw |
Vertical axial motor | 0.75 kw |
Horizontal axial motor | 0.4 kw |
Hopper volume | 100 L |
Height of hopper | 1301 mm |
Machine size | L2160 x W1021 x H1655 |
Cycle time (According to each material) | 30 sec. |
Compressing capacity (According to each material) | 60-90 kg/hr |
Machine weight (With hydraulic oil) | 1800 kg |
